S no. | Specification | |
---|---|---|
1 | standard cliche plate size | 210 * 100* 10 mm |
2 | maximum printing diameter | 80 |
3 | printing capacity | 1800 prints/ hour |
4 | maximum height of product | 80mm |
5 | drive | pneumatic |
6 | printing force | 500n at 6 bar |
7 | compressed air connection | 5-6 bar working pressure |
8 | air consumption | 4.8Nm³/hr at 6 bar |
9 | electronic control system | With 10 inputs & 6 outputs each for peripheral units With 4 inputs & 4 outputs for integration into production lines |
10 | pad vertical stroke | Maximum 100mm Infinitely adjustable |
11 | speed adjustment | Infinitely Adjustable Via Pneumatic Choke |
11 | dimensions | Length- 810mm width- 330mm Height- 690mm |
12 | weight | varies available on request |
