2 colour, 3 colour, 4 colour printing.
S no. | Specification | |
---|---|---|
1 | standard cliche plate size | 140 * 70* 10mm |
2 | maximum printing diameter | 50 |
3 | printing capacity | 2800 prints/ hour |
4 | maximum height of product | 50mm |
5 | drive | pneumatic |
6 | printing force | 300n at 6 bar |
7 | compressed air connection | 5-6 bar working pressure |
8 | air consumption | 4.8nm/ hr at 6 bar |
9 | electronic control system | with 10 inputs & 6 outputs each for peripheral units |
10 | pad vertical stroke | length- 100mm |
11 | speed adjustment | Infinitely Adjustable Via Pneumatic Choke |
11 | dimensions | Length - 610 mm Width - 300 mm Height - 480 mm |
12 | weight | varies available on request |
